Copeland™ FFWP-015Z-TFC-020

Description

Copeland™ Water Cooled Condensing Unit, Series: FFWP Series, Model: FFWP-015Z-TFC, 13 lb Nominal Capacity, 18000 Btu/hr, 208 to 230 V, 12.5 A, 1-1/2 hp HP Rating, 60 Hz, 3 ph, R-134A, R-22, R-404A, R-407C, 7/8 in Liquid Line, 3/8 in Suction Line, Sweat, 20 A Fuse, 5 deg F, 45 deg F, Steel, 16.6 in H x 16.9 in W x 24 in D

Features

• Multiple refrigerant
• General three lead single voltage, six lead part winding (575 V), nine lead dual voltage compressor motor
• Internal inherent protection, one protector use with contactor
• Bill of material include suction valve, receiver, box conduit, discharge line thermostat, high/low-pressure control, anti-short cycle time delay
• 40 A defrost relay rating
• Reliability, high-energy efficiency
• Low sound and vibration level
• Advanced diagnostics and protection features faster troubleshooting
• Factory installed EK filter drier and HMI moisture indicator fewer the leaks, reduced callbacks, lower installation costs, increased equipment reliability
• Modular components
• Replacement serviceability
• Multi-refrigerant approval for high/medium model
• Application flexibility, inventory consolidation
• Copeland™ scroll compressors on all model
