Copeland™ ZF11K4E-TF5-931
Copeland™ ZF ZF11K4E-TF5-931 Scroll Compressor, 200 - 220 VAC, 1390 W, 3-1/2 hp
Brand: Copeland™
Item No: ZF11K4E-TF5-931
Sign In for Availability
Description
Copeland™ Scroll Compressor, Series: ZF, 11000 Btu/hr BTU, 3/4 in Stub Suction Line, 1/2 in Stub Discharge Line, 115 - 169 lb/hr, 5.857 cu-ft/min, 200 - 220 VAC, 10 A, 1390 W, 3-1/2 hp, R-404A, R-134A, R-22, R-407A, R-407C, R-407F, HFC Refrigerant, 2900 rev/min Speed, 74 - 79 dBA, 6.8 - 9.3 EER, POE-AK/DA, 3MA/SP32 Compressor Oil, -25 to-40 deg F Evaporator, 50 deg F Condensing, Liquid, 65 deg F Return Gas, 9.57 in L x 9.52 in W x 16.46 in H
Features
- General 3-lead single voltage, 6-lead part winding (575 V)
- Internal inherent protection
- Compressor family Series
- Model variation
- 49 oz initial oil charge, 45 oz oil recharge
- 251 cu-in internal free volume
- 7-1/2 in L x 7-1/2 in W x 16.69 in H mounting
- 3.49 cu-in/rev displacement
- 11.8 A-rated load, 89 A locked rotor, 16.5 A minimum circuit, 14.5 maximum operating
- Bill of material-top cap well, flag terminal, stub connection, mounting parts, sight glass and oil access fitting
Specifications
|
Amperage Rating |
10 A |
|
BTU Rating |
11000 Btu/hr |
|
CFM Rating |
5.857 cfm |
|
Compressor Oil |
POE-AK/DA, 3MA/SP32 |
|
Dimensions |
9.57 in L x 9.52 in W x 16.46 in H |
|
Discharge Line Size |
1/2 in Stub |
|
EER Rating |
6.8 to 9.3 |
|
Flow Rate |
115 to 169 lb/hr |
|
Power Rating |
1390 W, 3-1/2 hp |
|
Refrigerant Type |
R-404A, R-134A, R-22, R-407A, R-407C, R-407F, HFC |
|
Series |
ZF |
|
Sound Level |
74 to 79 dBA |
|
Speed Rating |
2900 rpm |
|
Suction Line Size |
3/4 in Stub |
|
Temperature Rating |
-25 to -40 deg F Evaporator, 50 deg F Condensing, Liquid, 65 deg F Return Gas |
|
Voltage Rating |
200 to 220 VAC |
