Copeland™ ZF18KVE-TF5-961
Copeland™ ZF ZF18KVE-TF5-961 Scroll Compressor, 200 - 230 VAC, 4950 W, 6 hp
Brand: Copeland™
Item No: ZF18KVE-TF5-961
Sign In for Availability
Description
Copeland™ Scroll Compressor, Series: ZF, 18000 Btu/hr BTU, 7/8 in Stub Suction Line, 1/2 in Stub Discharge Line, 233 - 349 lb/hr, 12.118 cu-ft/min, 200 - 230 VAC, 14.8 A, 4950 W, 6 hp, R-404A, R-134A, R-22, R-407A, R-407C, R-407F, HFC Refrigerant, 3500 rev/min Speed, 80 - 85 dBA, 4.7 - 5.9 EER, POE-AK/DA, 3MA/SP32 Compressor Oil, -25 to-40 deg F Evaporator, 105 deg F Condensing, Liquid, 65 deg F Return Gas, 12.12 in L x 9.67 in W x 17.23 in H
Features
- General 3-lead single voltage, 6-lead part winding (575 V)
- Internal inherent protection
- Model variation
- 64 oz initial oil charge, 60 oz oil recharge
- 344 cu-in internal free volume
- 7-1/2 in L x 7-1/2 in W x 17.98 in H mounting
- 5.98 cu-in/rev displacement
- 21.8 A-rated load, 156 A locked rotor, 30.5 A minimum circuit, 26 maximum operating
- Bill of material-top cap well, flag terminal, rotalock connection, mounting parts, sight glass and oil access fitting
Specifications
|
Amperage Rating |
14.8 A |
|
BTU Rating |
18000 Btu/hr |
|
CFM Rating |
12.118 cfm |
|
Compressor Oil |
POE-AK/DA, 3MA/SP32 |
|
Dimensions |
12.12 in L x 9.67 in W x 17.23 in H |
|
Discharge Line Size |
1/2 in Stub |
|
EER Rating |
4.7 to 5.9 |
|
Flow Rate |
233 to 349 lb/hr |
|
Power Rating |
4950 W, 6 hp |
|
Refrigerant Type |
R-404A, R-134A, R-22, R-407A, R-407C, R-407F, HFC |
|
Series |
ZF |
|
Sound Level |
80 to 85 dBA |
|
Speed Rating |
3500 rpm |
|
Suction Line Size |
7/8 in Stub |
|
Temperature Rating |
-25 to -40 deg F Evaporator, 105 deg F Condensing, Liquid, 65 deg F Return Gas |
|
Voltage Rating |
200 to 230 VAC |
