DiversiTech® EL3636-3
DiversiTech® E-Lite® EL3636-3 Equipment Pad, 36 in L, 36 in W, 3 in H, Polypropylene, Gray
Brand: DiversiTech®
Item No: EL3636-3
Sign In for Availability
Description
The E-Lite® EL3636-3 is a 36 x 36 x 3 in gray plastic pad designed as a mounting base for condenser equipment. E-Lite® is injection molded from polypropylene, creating a pad that is lightweight, but durable. It is constructed with generous ribbing for optimum strength and self-leveling ground support. It is made with 98% recycled, UV-inhibited material resulting in an environmentally friendly, weather-resistant equipment pad.
DiversiTech® Equipment Pad, 1320 lb Capacity, -48 to 180 deg F, Polypropylene, Gray, 36 in Length, 36 in Width, 3 in Height, Domestic/Import: Domestic
Features
- Engineered with uniform and generous ribbing for level loading, optimum strength and self-leveling ground support
- Unaffected by UV exposure or extreme weather
- Environmentally friendly, made from 98% recycled plastic
- A subtle texture on pad surface prevents unit slide
- Each pad is constructed with its size in raised letters on the side of the pad for easy identification
- Tested per ASTM D2299 with refrigerants, synthetic canine urine, compressor oil or salt solution
- Drillable making it easy-to secure equipment to the pad if necessary
Specifications
|
Capacity |
1320 lb |
|
Color |
Gray |
|
Domestic/Import |
Domestic |
|
Height |
3 in |
|
Length |
36 in |
|
Material |
Polypropylene |
|
Temperature Rating |
-48 to 180 deg F |
|
Width |
36 in |
