Fluke® 4910269

Description

The Fluke T6-1000 electrical tester with FieldSense™ technology lets you quickly, safely take True rms voltage and current measurements without test leads. Unlike other fork testers that merely detect voltage, the T6-1000 makes actual measurements, without contacting a live, metallic conductor. Just slide the 17.8 mm open fork, the widest in the industry, over a conductor and read simultaneous voltage and current values. Or simultaneous frequency and current values. The open fork works with wires up to AWG 4/0 Or you can use the attached test leads to measure voltage DC to 1000 V.

Fluke® Electrical Tester, T6-1000 Series, 1000 VAC/VDC, 45 to 66 Hz, Cat III 1000 V, Cat IV 600 V Safety Rating, 20 to 100 kOhm Resistance, Alkaline Battery, 4/0 AWG Cord, 200 A Current, 61.1 x 259.3 x 43.8 mm Dimension, -10 to 50 deg C Operating Temperature, 2000 m Altitude, 360 hr Continuous, Typical 200 hr Using FieldSense Battery Life

Features

• Simultaneously measure voltage and current
• Hold button temporarily freezes the reading for easy viewing
• Easy-to-read display with backlight
• Standard two year warranty extendable to four years through product registration within 45 days of purchase

Specifications

Documentation
