Gastite® XR3FTG-8
Gastite® XR3FTG-8 FlashShield Fitting Adapter, 1/2 in MNPT x 1/2 in MNPT, Brass
Brand: Gastite®
Item No: XR3FTG-8
Sign In for Availability
Description
XR3 fittings are designed with a patented feature that contours the metal shield. This creates electrical continuity throughout the system. The XR3 fitting requires minimal torque for easy fitting installation. With no O-rings or gaskets, the reusable brass components provide a reliable metal-to-metal seat.
Gastite® FlashShield Fitting Adapter, Series: XR3 Series, Adapter Fitting, 1/2 in Connection Size 1, MNPT Connection Type 1, 1/2 in Connection Size 2, MNPT Connection Type 2, MNPT|MNPT Connection, Brass, CA360 Brass Material Construction, 25 psi, 1-1/8 in, -40 to 160 deg F
Features
- Metal locking feature
- Tool-free flare fitting design
- Metal-to-metal multi-point seal with no O-ring or gasket
- Self-guiding fitting assembly
- Approved for concealed use
- Patented jacket lock
- Fully reusable fitting
- Quick and easy installation
- No split rings, O-rings or gaskets
- For used to connect the flexible gas piping to the gas supply, distribution manifolds or gas appliances
Specifications
|
Connection Type |
MNPT |
|
Dimensions |
1-1/8 in |
|
Material |
Brass |
|
Pressure Rating |
25 psi |
|
Series |
XR3 Series |
|
Size |
1/2 in |
|
Temperature Rating |
-40 to 160 deg F |
Documentation
