Henry Group® F6307
Henry Group® F6307 Magnetic Check Valve, 3/8 in Nominal, ODS Connection, 800 psi Pressure, Solid Copper Body
Brand: Henry Group®
Item No: MS-6
Sign In for Availability
Description
Henry Group® Magnetic Check Valve, Model: MS-6, ODS Connection, 3/8 in Nominal, 800 psi, Solid Copper Body, Brass Seat, -20 to 250 deg F, 4 in L x 7/8 in W
Features
- Designed for maximum flow and minimal pressure drop
- Negligible loss in system efficiency
- Hermetically sealed copper body
- Stable platform with no chance of a leak
- Efficient sealing with a negligible leak rate
- Able to be installed in any position
- Built-in 30 mesh strainer to remove debris from the system and extend the valve service life
- Suitable for a wide range of applications
- Aluminum retainer
- Stainless steel flapper and screen
- Cost effective
- Optimized seat material with a neoprene--coated valve plate
Specifications
|
Body Material |
Solid Copper |
|
Connection Type |
ODS |
|
Dimensions |
4 in L x 7/8 in W |
|
Model |
MS-6 |
|
Nominal Size |
3/8 in |
|
Pressure Rating |
800 psi |
|
Seat Material |
Brass |
|
Temperature Rating |
-20 to 250 deg F |
Documentation
