Honeywell T991A1244/U
Honeywell T991A1244/U Temperature Control, 24 - 30 VAC, Temperature Settings: 55 - 175 deg F, Gray
Brand: Honeywell
Item No: T991A1244
Sign In for Availability
Description
Honeywell Temperature Control, T991A Model, 24 - 30 VAC, 5 ft Capillary Length, Sensing Element: Copper Bulb, 50/60 Hz, Temperature Settings: 55 - 175 deg F, Gray, 2 in L, 5-5/8 in H, 2-1/4 in W, 200 deg F Maximum
Features
- Fast response models (for duct-mounting) have coiled sensing element giving at least 4-times faster response than standard models
- Ambient temperature compensated for the case and tubing
- Sensing element capillary tubing allows remote-mounting of sensing element
- Setpoint may be read and adjusted through cover
- Throttling dial inside case adjusts proportional throttling range
- Setpoint automatically reset as outdoor temperature changes
- (1) 135 ohm potentiometer analog output
- 3.5 - 36 deg F throttling range
- Includes 107324A duct bulb holder
- 1-sensor inputs
Specifications
|
Capillary Length |
5 ft |
|
Color |
Gray |
|
Frequency Rating |
50/60 Hz |
|
Height |
5-5/8 in |
|
Length |
2 in |
|
Model |
T991A |
|
Sensing Element |
Copper Bulb |
|
Temperature Rating |
200 deg F Maximum |
|
Temperature Settings |
55 - 175 deg F |
|
Voltage Rating |
24 - 30 VAC |
|
Width |
2-1/4 in |
