Johnson Controls A-4000-1037

Description

The A-4000 series oil removal and pressure reducing stations are available in single or dual PRV models in 10 or 20 scfm (4.7 or 9.4 L/s) maximum flow capacities. In addition, each unit features a four-way bypass valve, coalescing and activated charcoal oil removing filters, and is completely piped with copper tubing which reduces friction, allows higher flow rates, and meets fire codes in mechanical equipment rooms. The filter combination removes both oil aerosols and vapors to provide clean, oil free air for pneumatic control systems. All models provide maximum performance for a period of one year at which time the coalescing and activated charcoal filter elements will need to be replaced. Gauges are provided to monitor system operations and performance. All models can provide filtered, high pressure air to remote PRV stations..

Johnson Controls In-Line Filter, Series: A-4000 Series

Features

• Combining coalescing and activated carbon filters in Series provides clean, oil-free air by removing both oil aerosols and vapors in pneumatic control systems
• In-line oil indicating supply air filter, barbed connections for 1/4 in OD polytubing, 861 kPa maximum input pressure
• 120 deg F temperature rating
