Marathon® C167A
Marathon® C167A General Purpose Motor, 115/230 V, 4.6/2.3 A, 0.5 hp, 1725 rpm Speed, 0.37 kW, 1 ph -Phase, 60 Hz
Brand: Marathon®
Item No: C167A
Sign In for Availability
Description
Marathon® General Purpose Motor, 115/230 V, 4.6/2.3 A, 0.5 hp, 1725 rpm Speed, 0.37 kW Power, 1 ph, 60 Hz, Drip-Proof Motor Enclosure, 56 Frame, 0.625 in Dia x 1.97 in L Shaft, CCW Rotation, 1 Speed, Ball, 4 -Pole, Continuous, Across The Line, Class B, 76.2 % Efficiency, 1.25, 91.6, Rigid Base Mount, Rolled Steel, 40 deg C Ambient, 11.47 in L, Horizontal Motor Orientation, NEMA 56 Shaft Type
Features
- UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications
- Premium efficiency promotes improved reliability
- Heavy-duty, rolled steel construction ensures motor durability
- Permanently lubricated, double-sealed bearings extend the lifetime of the motor
Specifications
|
Additional Information |
Horizontal Motor Orientation, NEMA 56 Shaft Type |
|
Amperage Rating |
4.6/2.3 A |
|
Bearing Type |
Ball |
|
Dimensions |
11.47 in L |
|
Duty Type |
Continuous |
|
Efficiency |
76.2 % |
|
Frame Size |
56 |
|
Frequency Rating |
60 Hz |
|
HP Rating |
0.5 hp |
|
Insulation Class |
Class B |
|
Material |
Rolled Steel |
|
Motor Enclosure Type |
Drip-Proof |
|
Mounting Type |
Rigid Base |
|
Number of Poles |
4 |
|
Number of Speeds |
1 |
|
Phase |
1 ph |
|
Power Factor |
91.6 |
|
Power Rating |
0.37 kW |
|
Rotation Type |
CCW |
|
Service Factor |
1.25 |
|
Shaft Size |
0.625 in Dia x 1.97 in L |
|
Speed Rating |
1725 rpm |
|
Starting Method |
Across The Line |
|
Temperature Rating |
40 deg C Ambient |
|
Voltage Rating |
115/230 V |
