Mars® 00809
Mars® 00809 Motor, 115 VAC, 0.89 A, 1/47 hp, 1550 rpm Speed, 18 W, 50 Hz, 60 Hz, Air Over Motor Enclosure
Brand: Mars®
Item No: 00809
Sign In for Availability
Description
Mars® Motor, 115 VAC, 0.89 A, 1/47 hp, 1550 rpm, 18 W, 50 Hz, 60 Hz, Air Over Motor Enclosure, 1-1/4 in L Shaft, Counter-Clockwise Shaft End Rotation, 1 Speed, Sleeve Bearing, B Insulation Class, -40 to 104 deg F, 2.8 in Dia x 4.82 in L
Features
- Thermal protection
- Continuous air-over
- Impedance and thermal protected
- Three tapped holes at 120 deg and two tapped holes at 180 deg
- Single side pad mounting
- Four shaft-end studs
Specifications
|
Amperage Rating |
0.89 A |
|
Bearing Type |
Sleeve |
|
Dimensions |
2.8 in Dia x 4.82 in L |
|
Frequency Rating |
50 Hz, 60 Hz |
|
HP Rating |
1/47 hp |
|
Insulation Class |
B |
|
Motor Enclosure Type |
Air Over |
|
Number of Speeds |
1 |
|
Power Rating |
18 W |
|
Rotation Type |
Counter-Clockwise Shaft End |
|
Shaft Size |
1-1/4 in L |
|
Speed Rating |
1550 rpm |
|
Temperature Rating |
-40 to 104 deg F |
|
Voltage Rating |
115 VAC |
