Mars® 4686
Mars® 4686 Fan/Blower Motor, 115/208 to 230 VAC, 13.3/6.5 to 6.6 A, 3/4 hp, 1725 rpm Speed, 60 Hz, 56Z Frame
Brand: Mars®
Item No: 4686
Sign In for Availability
Description
Mars® Fan/Blower Motor, 115/208 to 230 VAC, 13.3/6.5 to 6.6 A, 3/4 hp, 1725 rpm, 60 Hz, Drip-Proof Motor Enclosure, 56Z Frame, 5/8 in Dia x 2-1/4 in L Shaft, 1 Speed, Ball Bearing, Resilient Base Mounting, Belt Drive, Continuous, B Insulation Class, 1.25 Service Factor, Steel, 40 deg C, 11.15 in L
Features
- Automatic thermal protection
Specifications
|
Amperage Rating |
13.3/6.5 to 6.6 A |
|
Bearing Type |
Ball |
|
Dimensions |
11.15 in L |
|
Drive Type |
Belt |
|
Duty Type |
Continuous |
|
Frame Size |
56Z |
|
Frequency Rating |
60 Hz |
|
HP Rating |
3/4 hp |
|
Insulation Class |
B |
|
Material |
Steel |
|
Motor Enclosure Type |
Drip-Proof |
|
Mounting Type |
Resilient Base |
|
Number of Speeds |
1 |
|
Service Factor |
1.25 |
|
Shaft Size |
5/8 in Dia x 2-1/4 in L |
|
Speed Rating |
1725 rpm |
|
Temperature Rating |
40 deg C |
|
Voltage Rating |
115/208 to 230 VAC |
Documentation
