Mitsubishi Electric MUZ-GX12NL MUZ-GX12NL

Mitsubishi Electric MUZ-GX12NL

Mitsubishi Electric MUZ-GX12NL Ductless Mini-Split Heat Pump Outdoor Unit, 208/230 V, 0.71 A, 12000 Btu/hr Cooling

Brand: Mitsubishi Electric

Item No: MUZ-GX12NL

Sign In for Availability
loading
Add To Cart

Email Print

Description

Mitsubishi Electric Ductless Mini-Split Heat Pump Outdoor Unit, 208/230 V, 0.71 A, 900 W Cooling, 1100 W Heating, 60 Hz, 1 ph, 14400 Btu/hr Heating, 12000 Btu/hr Cooling, 1139 cfm Heating CFM Rating, 1152 cfm Cooling CFM Rating, 13.35 EER Rating, 25.6 SEER, 10.7 HSPF, Flared Connection, Twin Rotary Compressor, R-454B Refrigerant, 1/4 in Liquid Line, 3/8 in Suction Line, 15 A Fuse Rating, 51 dBA Heating Sound Level, 49 dBA Cooling Sound Level, Wall Mounting, Finish: Munsell 3Y 7.8/1.1, -5 to 75 deg F Heating Operating Temperature, 14 to 115 deg F Cooling Operating Temperature, 11-1/4 in Overall Length, 31-1/2 in Overall Width, 21-5/8 in Overall Height

Features

  • Blue Fin Coating: An anti-corrosion treatment applied to the aluminum fins of the heat exchanger of the outdoor unit to protect against corrosion caused by salt, sulfur, and other airborne contaminants, especially in coastal and industrial areas
  • INVERTER-driven compressor: An inverter-driven compressor generates the precise capacity needed to maintain a temperature set point
  • Powered by Outdoor Unit: The outdoor unit powers the indoor unit, and should a power outage occur, the system is automatically restarted when power returns

    • Specifications

    Amperage Rating

    		0.71 A

    Compressor Type

    		Twin Rotary

    Connection Type

    		Flared

    Cooling BTU Rating

    		12000 Btu/hr

    Cooling CFM Rating

    		1152 cfm

    Cooling Operating Temperature

    		14 to 115 deg F

    Cooling Sound Level

    		49 dBA

    EER Rating

    		13.35

    Finish

    		Munsell 3Y 7.8/1.1

    Frequency Rating

    		60 Hz

    Fuse Rating

    		15 A

    HSPF Rating

    		10.7

    Heating BTU Rating

    		14400 Btu/hr

    Heating CFM Rating

    		1139 cfm

    Heating Operating Temperature

    		-5 to 75 deg F

    Heating Sound Level

    		51 dBA

    Liquid Line Size

    		1/4 in

    Mounting Type

    		Wall

    Overall Height

    		21-5/8 in

    Overall Length

    		11-1/4 in

    Overall Width

    		31-1/2 in

    Phase

    		1 ph

    Power Rating

    		900 W Cooling, 1100 W Heating

    Refrigerant Type

    		R-454B

    SEER Rating

    		25.6

    Suction Line Size

    		3/8 in

    Voltage Rating

    		208/230 V
