Mitsubishi Electric MXZ-2C20NAHZ3-U1
Mitsubishi Electric MXZ-2C20NAHZ3-U1 Multi‐Split Cold Climate Air Source Heat Pump System, 208/230 V, 29.5 A
Brand: Mitsubishi Electric
Item No: MXZ2C20NAHZ3-U1
Sign In for Availability
Description
Mitsubishi Electric Multi‐Split Cold Climate Air Source Heat Pump System, 208/230 V, 29.5 A, 2.43 W, 60 Hz, 1 ph, 20000 Btu/hr Heating BTU Rating, 22000 Btu/hr Cooling BTU Rating, 2550 cfm Heating CFM Rating, 2150 cfm Cooling CFM Rating, 11 EER, 15 SEER, HSPF: 9.5, Flared, Inverter Compressor, 1/4 in Liquid Line, 40 A Fuse, 58 dBA Heating Sound Level, 54 dBA Cooling Sound Level, Munsell, -13 to 65 deg F Heating Operating Temperature, 14 to 115 deg F Cooling Operating Temperature, 37‐13/32 in Overall Width, 41‐17/64 in Overall Height, Additional Information: 13 in Depth
Features
- Variable speed Inverter
- M‐NET connection optional through outdoor unit
- Quiet outdoor unit operation as low as 54 dBA
- High pressure switch for additional protection
- Built‐in base pan heater
Specifications
|
Additional Information |
13 in Depth |
|
Amperage Rating |
29.5 A |
|
Color |
Munsell |
|
Compressor Type |
Inverter |
|
Connection Type |
Flared |
|
Cooling BTU Rating |
22000 Btu/hr |
|
Cooling CFM Rating |
2150 cfm |
|
Cooling Operating Temperature |
14 to 115 deg F |
|
Cooling Sound Level |
54 dBA |
|
EER Rating |
11 |
|
Frequency Rating |
60 Hz |
|
Fuse Rating |
40 A |
|
HSPF Rating |
9.5 |
|
Heating BTU Rating |
20000 Btu/hr |
|
Heating CFM Rating |
2550 cfm |
|
Heating Operating Temperature |
-13 to 65 deg F |
|
Heating Sound Level |
58 dBA |
|
Liquid Line Size |
1/4 in |
|
Overall Height |
41���17/64 in |
|
Overall Width |
37���13/32 in |
|
Phase |
1 ph |
|
Power Rating |
2.43 W |
|
SEER Rating |
15 |
|
Voltage Rating |
208/230 V |
