Mitsubishi Electric MXZ-SM36NAM-U1

Description

Mitsubishi Electric SMART MULTI® Multi-Zone Inverter Heat Pump System, Model: MXZ-SM, 208/230 V, 2400 W, 2610 W, 2760 W, 2825 W, 2855 W, 2890 W, 3080 W, 3200 W, 3325 W, 60 Hz, 1 ph, 42000 Btu/hr Heating BTU Rating, 36000 Btu/hr Cooling BTU Rating, 3885 cfm Heating CFM Rating, 3885 cfm Cooling CFM Rating, 12.6, 13.8, 15 EER, 18.3, 23 SEER, HSPF: 11.2, 12.5, Flared, Variable Speed Inverter Driven Compressor, 3/8 in Liquid Line, 5/8 in Suction Line, 30 A Fuse, 3 ton, 53 dBA Heating Sound Level, 49 dBA Cooling Sound Level, 52-11/16 in Overall Length, 41-11/32 in Overall Width, 13 in Overall Height

Features

• Multi-zone, heat pump outdoor unit, Blue Fin anti-corrosion treatment on heat exchanger
• Compatible with M and P Series and City Multi® indoor units, branch box required for connection with M and P Series
• Seacoast protection on heat exchanger and base panel (rated for 2000 hr in accordance with ASTM B117 testing)
• Thermal differential 1 deg F (with PAC-MKA32/52BC only)
• Optional base pan heater
• Quiet outdoor unit operation, rated sound pressure as low as 49 dBA
• High pressure protection
• Compressor thermal protection
• Compressor overcurrent detection
• Fan motor overheating/voltage protection
