MUELLER INDUSTRIES A 14848
MUELLER INDUSTRIES A 14848 Packless Diaphragm Valve, 1/4 in Nominal, Solder x Solder Extended End Connection
Brand: MUELLER INDUSTRIES
Item No: A-14848
Sign In for Availability
Description
Lifecycle testing has shown that Streamline's packless diaphragm valves perform up to 5-times greater than current industry standards. Valve bodies are forged brass with full-size openings for maximum flow and minimum pressure drop and feature integral mounting brackets for ease of installation. Oversized diaphragms produce a perfect combination of long wear and precise sealing. Counter seat design ensures no moisture intrusion.
MUELLER INDUSTRIES Packless Diaphragm Valve, 1/4 in Nominal, Solder x Solder Extended End, 700 psi, Forged Brass Body, Hand Wheel Operator, -40 to 300 deg F, 5.38 in L x 2.7 in H
Features
- Maximum abnormal pressure (MAP) With the flow in the direction of the arrow on the body 700 psi, against the direction of the arrow on the body 300 psi and burst pressure is 2500 psi
- Forged brass body with full size openings for maximum flow and minimum pressure drop
- Diaphragms for positive isolation
- Thermally stable hand wheel for operation in wide temperature ranges
- (2) stainless steel diaphragms and (1) phosphor bronze diaphragm for positive isolation
- For CFC, HCFC and HFC refrigerants and oils
Specifications
|
Body Material |
Forged Brass |
|
Connection Type |
Solder x Solder Extended End |
|
Dimensions |
5.38 in L x 2.7 in H |
|
Nominal Size |
1/4 in |
|
Operator Type |
Hand Wheel |
|
Pressure Rating |
700 psi |
|
Temperature Rating |
-40 to 300 deg F |
