Pdm F100.GUS788212
Pdm GelCopper™ F100.GUS788212 Pre-Insulated Lineset Roll, 82 ft L, 1/2 in Thick Insulation, Copper
Brand: Pdm
Item No: 7/8OD X 1/2WALL X 82'
Sign In for Availability
Description
Pdm GelCopper™ Pre-Insulated Lineset Roll, 82 ft L, 700 psi Pressure, 7/8 in Dia, 1/2 in Thickness Insulation, ASTM B1003, ASTM B280, ASTM C1427-07, Copper, -94 to 250 deg F, Domestic/Import: Domestic
Features
- Individual pre-insulated rolls for increased versatility and use on ductless mini splits, VRF and heat pumps
- Cu29BA patent pending technology provides strong anti-corrosion properties to copper tubes reducing any risk of formicary/pitting corrosion
- Additional white polyethylene jacket cover protects foam insulation from tearing during installation process
- Insulation incrementally marked by every foot to ensure accurate initial unit charge and reduce copper waste
- R410 can be used in applications where high pressure gases are used as a refrigeration source
- This product is UL performance verified for UV exposure and successfully tested internally for UV-resistance for a minimum of 5 year
- The insulation can be painted to match the surroundings
- LDPE closed cell foam insulation
Specifications
|
Diameter |
7/8 in |
|
Domestic/Import |
Domestic |
|
Insulation Thickness |
1/2 in |
|
Length |
82 ft |
|
Material Standard |
ASTM B1003, ASTM B280, ASTM C1427-07 |
|
Material |
Copper |
|
Pressure Rating |
700 psi |
|
Temperature Rating |
-94 to 250 deg F |
