PROTECH™ 51-102500-03
PROTECH™ 51-102500-03 Condenser Motor, 208/220/230 VAC, 0.8 A, 1/6 hp, 825 rpm Speed, 1 ph -Phase, 50 Hz, 60 Hz
Brand: PROTECH™
Item No: 51-102500-03
Sign In for Availability
Description
PROTECH™ Condenser Motor, 208/220/230 VAC, 0.8 A, 1/6 hp, 825 rpm, 1 ph Phase, 50 Hz, 60 Hz, 1/2 in Dia x 2-1/16 in L Shaft, Counter-Clockwise Rotation, 1 Speed, Sleeve Bearing, End-Boss, Shell Band Mounting, Direct Drive, 5-5/8 in Dia x 6-3/8 in L
Features
- Capacitor 5 uF at 370 VAC
Specifications
|
Amperage Rating |
0.8 A |
|
Bearing Type |
Sleeve |
|
Dimensions |
5-5/8 in Dia x 6-3/8 in L |
|
Drive Type |
Direct |
|
Frequency Rating |
50 Hz, 60 Hz |
|
HP Rating |
1/6 hp |
|
Mounting Type |
End-Boss, Shell Band |
|
Number of Speeds |
1 |
|
Phase |
1 ph |
|
Rotation Type |
Counter-Clockwise |
|
Shaft Size |
1/2 in Dia x 2-1/16 in L |
|
Speed Rating |
825 rpm |
|
Voltage Rating |
208/220/230 VAC |
