Ranco A30-301
Ranco A30 A30-301 Freezer Control, 24/120/240/277 V, 20/16 A Full Load, 80/60 A Locked Rotor, Configuration: SPST
Brand: Ranco
Item No: A30-301
Sign In for Availability
Description
These compact controls are readily adaptable to nearly all commercial refrigerators and freezers. A wide section of temperature ranges, differentials, and capillary lengths are available. Break-off shafts are included with installation instructions for easy, fast installation. Controls have "off" position except as noted.
Ranco Freezer Control, Series: A30, 20/16 A Full Load, 80/60 A Locked Rotor, 24/120/240/277 V, Configuration: SPST, Switching Action: Close on Rise, 84 in Capillary Length, 240 V-A Pilot Duty Contact, 8.5 deg F Differential, Temperature Settings: -3 to 5.5 deg F, 1-1/4 in L, 1-1/2 in H, 1-1/4 in W, 20.5 deg F Warm On, -24 deg F Cold Off
Specifications
|
Amperage Rating |
20/16 A Full Load, 80/60 A Locked Rotor |
|
Capillary Length |
84 in |
|
Configuration |
SPST |
|
Contact Rating |
240 V-A Pilot Duty |
|
Differential Temperature |
8.5 deg F |
|
Height |
1-1/2 in |
|
Length |
1-1/4 in |
|
Series |
A30 |
|
Switching Action |
Close on Rise |
|
Temperature Rating |
20.5 deg F Warm On, -24 deg F Cold Off |
|
Temperature Settings |
-3 to 5.5 deg F |
|
Voltage Rating |
24/120/240/277 V |
|
Width |
1-1/4 in |
