resideo TK300-60
resideo TK300-60 Heating Expansion Tank, 1/2 in Connection, MNPT Connection, Steel, 100 psi Pressure
Brand: resideo
Item No: TK300-60
Sign In for Availability
Description
resideo Heating Expansion Tank, 1/2 in Connection, MNPT Connection, Diaphragm Material: Butyl/EPDM, Steel, 100 psi Pressure, 240 deg F, 11 in Dia x 23 in L
Features
- Expansion tanks absorb hot water expansion in closed heating systems
- They are equipped with butyl diaphragms to separate the air from the system water
- Pre-pressurized, the tank keeps fluids circulating and maintains minimum pressure
Specifications
|
Connection Size |
1/2 in |
|
Connection Type |
MNPT |
|
Diaphragm Material |
Butyl/EPDM |
|
Dimensions |
11 in Dia x 23 in L |
|
Material |
Steel |
|
Pressure Rating |
100 psi |
|
Temperature Rating |
240 deg F |
