Rheem® 51-102728-23
Rheem® ECM Series 51-102728-23 Non-Programmable Condenser Motor, 1/3 hp, 208/230 V, 50/60 Hz, 1 ph-Phase, 39 Frame
Brand: Rheem®
Item No: 51-102728-23
Sign In for Availability
Description
Rheem® Non-Programmable Condenser Motor, Series: ECM Series, 1/3 hp HP Rating, 208/230 V, 2.8 A, 50/60 Hz, 1 ph, 1075 rpm Speed Rating, 39 Frame, 1/2 in Dia x 2-5/8 in L Shaft, Ball Bearing, Shell Band, Thru-Bolt Mount
Specifications
|
Amperage Rating |
2.8 A |
|
Bearing Type |
Ball |
|
Frame |
39 |
|
Frequency Rating |
50/60 Hz |
|
HP Rating |
1/3 hp |
|
Mounting Type |
Shell Band, Thru-Bolt |
|
Phase |
1 ph |
|
Series |
ECM Series |
|
Shaft Size |
1/2 in Dia x 2-5/8 in L |
|
Speed Rating |
1075 rpm |
|
Voltage Rating |
208/230 V |
