Rheem® RCFZ4824STANMC

Description

Rheem® Endeavor™ Furnace Cased Coil, Series: RCFZ Series, 48000 Btu/hr, 600 cfm, 1100 cfm, 1800 cfm, 1900 cfm CFM Rating, R-410A, 3/4 in, NPT, 16/2 Rows, 8.55 sq-ft Face Area, 24-1/2 in W x 21-11/16 in D, For Use With: UV-Resistant Germicidal Light Systems, Additional Information: Standard Efficiency, TXV Metering Device, Multi-Poise Orientation

Features

• When matched with RUUD® outdoor units, the coils provide a nominal capacity range from 18000 Btu/hr (5.24 kW) to 60000 Btu/hr (17.6 kW)
• Constructed of aluminum fins bonded to internally grooved aluminum tubing
• Coils are tested at the factory with an extensive refrigerant leak check
• Coils have copper sweat refrigerant connections
• Feature two sets of 3/4 in NPT condensate drain connections for ease of connection
• Chatleff metering device connections, at inlet and outlet of TXV or EEV and equalizer connections (TXV only)
• Approved for system application with variety of RUUD® outdoor units
• Condensate drain pan is constructed of high-grade, heat-resistant, corrosion-free thermal-setting material
• Bi-directional airflow eliminates the need to switch any internal components from horizontal left to right
• Unique drain pan design maximizes application flexibility and condensate removal
• N-coil design maximizes performance and minimizes height required at installation
• Coils are AHRI® certified for system application with a variety of RUUD® outdoor units
• For gas and oil furnaces
