Robertshaw® 1101B
Robertshaw® 1100 1101B Electric Timer, 120 VAC, 40/20 A, 1 -Pole, SPST, 24 hr Max Time Setting, NEMA 1, Metal Housing
Brand: Robertshaw®
Item No: 1101B
Sign In for Availability
Description
The Tork® 1100 Series electric timers offer 24 hr time switches with automatic on/off control when operation is required at the same time every day, seven days a week. Applications include on/off control of heating, air conditioning, display lighting, ventilating, pumps and fans. Tork® electric timers are sold exclusively through Robertshaw® to HVACR wholesalers.
Robertshaw® Electric Timer, Model: 1100, 120 VAC, 40/20 A, 3 W, 2 hp HP Rating, 1 Pole, SPST, On-Off Timing Modes, 24 hr Maximum Time Setting, NEMA 1, -40 to 165 deg F Operating, Metal Housing
Features
- Heavy-duty synchronous, self-starting high torque timing motor
- Automatic operation for 24 hr timers with one pair of on/off trippers supplied accommodates up to 12 pairs
- Multi-lingual dial markings English, French and Spanish
- Temporary manual override
- General purpose (NEMA 1) metal enclosure of deep-drawn steel, enamel-coated and lockable hasp
- Combination 1/2 in and 3/4 in knockouts on both sides, bottom and back
Specifications
|
Amperage Rating |
40/20 A |
|
Contact Form |
SPST |
|
HP Rating |
2 hp |
|
Housing Material |
Metal |
|
Maximum Time Setting |
24 hr |
|
Model |
1100 |
|
NEMA Rating |
NEMA 1 |
|
Number of Poles |
1 |
|
Operating Temperature |
-40 to 165 deg F |
|
Power Consumption |
3 W |
|
Timing Modes |
On-Off |
|
Voltage Rating |
120 VAC |
