Sporlan® 902926
Sporlan® 902926 Head Pressure Control Regulating Valve, 7/8 in Nominal, ODF Copper Solder Connection, 180 psi Pressure
Brand: Sporlan®
Item No: OROA-5-180 5/8X7/8
Sign In for Availability
Description
The Sporlan type OROA head pressure control valves have a brass body with copper connections. These valves are non-adjustable. They perform the function of limiting flow of refrigerant from the condenser and at the same time regulate the flow of hot gas around the condenser to the receiver during low ambient conditions, so as to keep the refrigerant in the liquid line at proper pressure. Each valve is factory tested to ensure positive leak-free performance. For over 80 years the Sporlan division of Parker Hannifin has set the industry standard for the development and manufacture of leading edge HVACR components. Our outside technical sales force and application engineering team focuses on refrigeration system applications and troubleshooting for service technicians, distribution channel partners, and original equipment manufacturers.
Sporlan® Head Pressure Control Regulating Valve, 7/8 in Nominal, ODF Copper Solder, 180 psi, 5/8 in Opening, Brass Body, 157 mm L x 102 mm H
Features
- Steel diaphragm
- 40 mesh insertable strainer type
Specifications
|
Body Material |
Brass |
|
Connection Type |
ODF Copper Solder |
|
Dimensions |
157 mm L x 102 mm H |
|
Nominal Size |
7/8 in |
|
Opening Size |
5/8 in |
|
Pressure Rating |
180 psi |
