Streamline® A 17515
Streamline® A 17515 Compressor Valve Kit, 7/8 in Nominal, Solder x Flange End, 700 psi Pressure, Brass Body
Brand: Streamline®
Item No: 998-0510-12
Sign In for Availability
Description
Streamline® Compressor Valve Kit, 7/8 in, Solder x Flange End, 700 psi Pressure, -40 to 300 deg F, Brass Body, 6.55 in W, Front Seat, 1-5/8 in Bolt Center, 0.34 in Bolt Hole, 1.55 lb Weight
Features
- 100% tested
- Asbestos‐free valve packing
- Valve openings designed for maximum flow and minimum pressure drop
Specifications
|
Additional Information |
Front Seat, 1-5/8 in Bolt Center, 0.34 in Bolt Hole, 1.55 lb Weight |
|
Body Material |
Brass |
|
End Type |
Solder x Flange |
|
Nominal Size |
7/8 in |
|
Pressure Rating |
700 psi |
|
Temperature Rating |
-40 to 300 deg F |
|
Width |
6.55 in |
Documentation
