WHITE-RODGERS™ 1F87U-42WF
WHITE-RODGERS™ 1F87U-42WF Wi-Fi Thermostat, 20 - 30 VAC, 1.5 - 2.5 A, 7 day Program Programmability
Brand: WHITE-RODGERS™
Item No: 1F87U-42WF
Sign In for Availability
Description
WHITE-RODGERS™ Wi-Fi Thermostat, 20 - 30 VAC, 1.5 - 2.5 A, 50/60 Hz, 7 day Program Programmability, Auto, Battery/Hardwired, 2 Heat/2 Cool Conventional Systems, 4 Heat/2 Cool Heat Pump Stages, HEAT-OFF-COOL-AUTO-AUXILIARY (System), AUTO-ON (Fan) Switch Position, 0.5 deg F at 6 deg F/hr Fast, 0.75 deg F at 6 deg F/hr Medium, 1.9 deg F at 6 deg F/hr Slow Heating, 0.9 deg F at 6 deg F/hr Fast, 1.2 deg F at 6 deg F/hr Medium, 1.7 deg F at 6 deg F/hr Slow Cooling, 0.9 deg F at 6 deg F/hr Fast, 1.2 deg F at 6 deg F/hr Medium, 1.7 deg F at 6 deg F/hr Slow Heating Pump (Heating and Cooling), 0.5 deg F at 6 deg F/hr Fast, 0.75 deg F at 6 deg F/hr Medium, 1.9 deg F at 6 deg F/hr Slow Heating Pump (Auxiliary) Differential Temperature, 50 - 99 deg F Temperature Settings, 32 - 105 deg F Ambient, -20 to 150 deg F Storage, 90% RH Non-Condensing Humidity Rating, Horizontal Mounting, RC, RH, C, W/E, W2, Y, Y2, O/B, G, L Terminal Designation, White, 5.88 in W x 3-3/4 in H x 1 in D
Features
- Geofencing - geofencing automatically changes temperatures based on the location of the homeowner's smartphone
- Smart alerts - smart alerts notify homeowners of extreme temperature or humidity levels
- Smart home compatible - compatible with smart home platforms apple home kit, amazon alexa and wink
- Easy to install - no c-wire required for most installations plus a built-in level for easy mounting
- Easy to connect to wi-fi - easy step-by-step guide in the app to connect to wi-fi
- Contractor-on-call - the sensi app stores your contact information so when your customer needs service, you're just a tap away
- Energy saving features - with features like geofencing, flexible scheduling and remote access, homeowners can save money without compromising their comfort
- Multi-thermostat control - easy management for schools and light commercial applications
- Circulating fan - improves air quality when a custom run time is set
- Advanced features - dual fuel applications, auto changeover, keypad lockout, backlit display, remote access, flexible scheduling, local weather, humidity sensor
- EMR/early start program
- Auto DST adjust
- Permanent memory
Specifications
|
Amperage Rating |
1.5 - 2.5 A |
|
Changeover |
Auto |
|
Color |
White |
|
Differential Temperature |
0.5 deg F at 6 deg F/hr Fast, 0.75 deg F at 6 deg F/hr Medium, 1.9 deg F at 6 deg F/hr Slow Heating, 0.9 deg F at 6 deg F/hr Fast, 1.2 deg F at 6 deg F/hr Medium, 1.7 deg F at 6 deg F/hr Slow Cooling, 0.9 deg F at 6 deg F/hr Fast, 1.2 deg F at 6 deg F/hr Medium, 1.7 deg F at 6 deg F/hr Slow Heating Pump (Heating and Cooling), 0.5 deg F at 6 deg F/hr Fast, 0.75 deg F at 6 deg F/hr Medium, 1.9 deg F at 6 deg F/hr Slow Heating Pump (Auxiliary) |
|
Dimensions |
5.88 in W x 3-3/4 in H x 1 in D |
|
Frequency Rating |
50/60 Hz |
|
Humidity Rating |
90% RH Non-Condensing |
|
Mounting Type |
Horizontal |
|
Power Source |
Battery/Hardwired |
|
Programmability |
7 day Program |
|
Stages |
2 Heat/2 Cool Conventional Systems, 4 Heat/2 Cool Heat Pump |
|
Switch Position |
HEAT-OFF-COOL-AUTO-AUXILIARY (System), AUTO-ON (Fan) |
|
Temperature Rating |
32 - 105 deg F Ambient, -20 to 150 deg F Storage |
|
Temperature Settings |
50 - 99 deg F |
|
Terminal Designation |
RC, RH, C, W/E, W2, Y, Y2, O/B, G, L |
|
Voltage Rating |
20 - 30 VAC |
