ZoomLock® 870811

Description

Parker ZoomLock® MAX refrigerant press fittings allow the contractor to successfully make leak-free connections with a press fitting system without the use of a brazing torch. ZoomLock® MAX refrigerant press fittings reduce installation costs, is more repeatable than brazing, improves system cleanliness and creates secure leak-free copper tube connections. ZoomLock® MAX refrigerant press fittings have a 15 year warranty and no crimp gauge needed to provide a safe secure connection.

ZoomLock® Reducer Coupling, Connection Size 1: 3/4 in, Connection Type 1: Press-to-Connect, Connection Size 2: 1/2 in, Connection Type 2: Press-to-Connect, Press|Press Connection, Copper, For Use With 32, 125, 134a, 290, 404A, 407A, 407C, 407F, 407H, 410A, 417A, 421A, 422B, 422D, 427A, 438A, 444A, 447A, 447B, 448A, 449A, 450A, 452A, 452B, 452C, 454A, 454B, 454C, 457A, 459A, 507A, 513B, 600A, 718, 1234yf, 1234ze and HYCOOL 20 Refrigerants, 700 psi Pressure, -40 to 250 deg F, HNBR O-Ring, 2100 psi Minimum Burst Pressure

Features

• Less equipment and no gas needed
• Safer conditions, no fire hazards
• No hot work permits required
• More environmentally friendly
• No solder related quality issues
• More flexible access to job sites
• No need to nitrogen purge
