Burnham® ALTAC-136B-1G02

Description

Burnham® High-Efficiency Gas Boiler, Model: ALTAC-136B, 120 V, AFUE Rating: 95 %, 13.6 to 120 mbh BTU, 50 psi Pressure, NPT x Sweat Connection, Natural Gas Fuel, Vent Type: Direct, Chimney/Breeching/Vent Size: 2 in, DOE Heating Capacity: 113 mbh, Net BTU Rating: 98 mbh, Stainless Steel, 30 in H x 18 in W x 16.3 in D, Domestic/Import: Domestic, 3/4 in Gas, 3/4 in DHW Outlet, 3/4 in Cold Water Inlet

Features

• No touch combustion set-up, engineered for 5 min start-up
• Self-diagnostic boiler control
• Rate-based temperature reset, no outdoor sensor required
• Assesses environmental conditions, continually adjusting boiler operation for comfort and efficiency
• Three-side unobstructed service access fast removal of front and side panels
• Simple two step natural gas to LP conversion with no kits or additional parts required
• Easy lift, wall hanging design
• Continuous high efficiency combustion without manual throttle or off-set adjustments
• Automatic self-calibration adjusts to variables in environment, component wear, gas and vent pressure
• Low gas pressure capability (2.5 in-WC gas, 8 in-WC LP)
• The world's first 10:1, gas adaptive combi boiler
• Virtually instantaneous DHW response time
• Selectable economy or comfort/recirculation modes
• DHW temperature maintained under all demand conditions
• 10:1 DHW turndown conserves fuel and extends boiler life
• Integrated DHW hydro block with quick disconnect flat plate DHW heat exchanger, boiler circulator, three way valve and instantaneous DHW flow sensor

Specifications

Documentation
