GeneralAire® 5144

Description

Water is dispersed evenly throughout a Vapor Pad inside the 1042LH. A portion of the heated air from the furnace passes through the water-soaked pad where it absorbs additional moisture and then returns for distribution throughout your home. Newly-moistened and healthier air is provided to you and your family.

GeneralAire® Whole House Humidifier, Series: Legacy Series, 24 V, 9-1/2 in H x 10-1/4 in W Plenum Opening, Manual Control, 17 gpd Capacity, 2800 sq-ft Coverage Area, 30 to 70 % Humidity Rating, 6 in Duct Opening, Plastic, 11-1/2 in H x 15 in W x 9 in D

Features

• Replacement vapor pad number 990-13 (GFI #7002), replace 1-2 times per season
• Shut-off damper
• Remove screws, lift off water distribution tube and trough to replace vapor pad
• Distributes water evenly throughout Vapor Pad for maximum evaporation
• Cover made with DuraPlast an ultra-violet stable automotive-grade plastic for long-lasting durability
• Bypass duct-mount to left or right
• Damper control knob open during use
• Inspection window Simply remove the GeneralAire badge
• Water is automatically drains from your humidifier
• Water intake tube - brings water into the unit
• Mounting hole for-mounting on return air duct or warm air plenum
• Delivers water to the water distribution trough
• Water evaporation via furnace heat
• Saddle valve and solenoid valve
• 6 in duct opening (assembly supplied)
• Return air duct or warm air plenum-mounting
