Mars® 61427
Mars® 614 Series 61427 Professional-Grade Definite Purpose Contactor, 208/240 V Coil, 30 A, 2-Pole
Brand: Mars®
Item No: 42AF15AG
Sign In for Availability
Description
Mars® Professional-Grade Definite Purpose Contactor, Series 614 Series, 208/240 V, 30 A, 2-Pole, Thermoplastic Housing, 3.19 in OAW, 2.38 in OAD, 2.87 in OAH, 50/60 Hz Coil, Box Lug/Dual QC Lug or Screw Terminal
Features
- Engineered for today's most demanding commercial refrigeration and HVAC applications
- Enclosed body provides a quieter running contactor and a longer life expectancy
- Oversized arch window to simplify wiring
- High performance copper and brass conductors maximize current carrying capability creating a cooler running contactor
- Multi-purpose coil terminals allow the use of QC terminals or stripped wires
- Removable coils allow field replacement of damaged coils
- Removable cover provides full access to the contacts
- Thermoplastic housing resists dusting and contamination of the contacts to maintain maximum conductivity
Specifications
|
Additional Information |
50/60 Hz Coil, Box Lug/Dual QC Lug or Screw Terminal |
|
Amperage Rating |
30 A |
|
Coil Voltage |
208/240 V |
|
Housing Material |
Thermoplastic |
|
Number of Poles |
2 |
|
Overall Depth |
2.38 in |
|
Overall Height |
2.87 in |
|
Overall Width |
3.19 in |
|
Series |
614 Series |
